3 in 1 Gobo Beam Wash Spot Moving Head Light 18R 380W DMX512 Touch Screen Stage Effect

Technical specification

Voltage: AC100-240V 50/60Hz

Bulb: 380W 18R

Lens: Quartz glass optical lens.

Channel: 26/20CH optional.(26CH standard,20 simple)

Color wheel 1: 11 colors + open with rainbow and flowing effect and speed controllable.

Color wheel 2: 6 colors mirror with rainbow colors.

Static gobo wheel: 14 gobos + open with shaking.

Rotation gobo wheel: 7 replaceable glass gobos + open.

Static effect gobos wheel: 5 gobos + open.

Prism 1: 8 facet prism.

Prism 2: 24 facet prism.

Prism 1 and Prism 2 can working together.

Zoom angle: 2.5~40°linear zoom and automatically zoom.

Frost: Frost lens create soft wash effect.

Focus: Electrical focus from fuzzy to clear.

Strobe: Electrical double patch strobe.0~13 times/S.

Dimmer: Electrical 0~100% linear dimmer adjust.

Pan angle: 540°(16Bit fine) Tilt angle: 270°(16Bit fine)

Control mode: DMX512,Master/slave,Auto-run,Sound active.Lamp On&Off and reset through controller or display.

Display: Touch screen with four buttons that can 180°reversed available.

Rated power: 550W

Channel List

Color wheel and 6 colors mirror

Static gobo wheel and Effect gobo wheel and Rotating gobo

Effect show

Body size

GUANGZHOU SUNWAY ENTERTAINMENT EQUIPMENT CO.,LTD, a member of the China Entertainment Technology Association (directed by the Ministry of Culture, P.R.C.), is a professional manufacturer who specializes in design, manufacture, sales and marketing of series of stage lightings products. At the same time, we are also professional in setting and adjusting several of stage projects, such as mega disco, night club, Karaoke ball room, multimedia conference room, in/outdoor background music broadcast, etc

We have more than 200 varieties of products, ranging from moving-heads, scan Lightings, follow spots, lasers, outdoor lightings, program lighting, gobo lighting, strobes, LED, speakers, amplifiers, etc. stage equipments

As improved our production management system and quality control system, optimized supply chains of raw materials, our productivity and quality of products have improved further. Many of our products have attained CE and ROHS certifications. Since our establishment, with plentiful project building experience, rich product resources and professional and. faithful after-sales services, we have met requirements from large quantity of customers, supplying solutions with perfect lightings and acoustics equipments and winning a good reputation and trust from every professional domestic and overseas customer we served.

As an active and aggressive team of enterprise, we firmly believe that “good quality is the life of an enterprise”. With principle of “innovating & developing, advancing towards the world", we are sincerely looking forward to creating our brilliant future with you---our distinguished clients, domestic and overseas.
