16PCS 30W LED Beam Moving Head Light , LED Spider Moving Head Light LCD Display

Ask Lasest Price
Brand Name :	Weinas
Model Number :	ML1630
Certification :	CE , Rohs
Price :	USD
Payment Terms :	L/C, T/T,
Supply Ability :	50 PCS Per Week
Delivery Time :	2 - 3 Days

Add to Cart

Product Details
Company Profile

16PCS 30W LED Beam Moving Head Light , LED Spider Moving Head Light LCD Display

16PCS 30W LED Beam Moving Head Light , LED Spider Moving Head Light , Stage Lighting

Advantage

Infinite Pan And Tilt Moving At Very High Speed , 16 PCS 30W LED , High Power Than Normal 10W

Specification

Lamp :16 × 30W( 4 in1 Color )
Channels :78 / 30 / 16 Channels
Control Mode : DMX512 Signal , Master-Salve Mode , Auto-Run Mode , Sound - Active Mode
Pan : 540degree Or Infinite Moving
Tilt : 360 degree Or Infinite Moving
Strobe : 1 - 25times / Second Or Random
Display Board : LCD Display Board
Rated Power : 600W
Net Weight : 30kg

Packing

60 x 55 x 50 cm ( 1 in 1 )

Channel List

CHS	Function	DMX Value	Specifications
CH1	Pan	0~255	0-540 degree
CH2	Pan infinite rotating	0~55	No Pan rotation
		56~155	Positive rotation, from fast to slow
		156~255	Negative rotation, from fast to slow
CH3	Pan Fine	0~255	16bitadjustment
CH4	Tilt	0~255	0~360degree
CH5	Tilt infinite rotating	0~55	No tilt function
		56~155	Positive rotation, from fast to slow
		156~255	Negative rotation, from fast to slow
CH6	Tilt fine	0~255	16bitadjustment
CH7	Pan/Tilt speed	0~255	From fast to slow
CH8	General dimming	0~255	from dark to bright linear Dimmer
CH9	Strobe	0~55	No function
		56~155	Frequency strobe, from slow to fast(1HZ~25HZ)
		156~205	Random strobe
		206~255	Lightning strobe
CH10	Area1 Red dimming	0~255	Area 1 Red dimming from dark to bright
CH11	Area 1 Green dimming	0~255	Area 1 Green dimming from dark to bright
CH12	Area 1 Blue dimming	0~255	Area 1 Blue dimming from dark to bright
CH13	Area1 white dimming	0~255	Area1 white dimming from dark to bright
CH14	Area2 Red dimming	0~255	Area2 Red dimming from dark to bright
CH15	Area2 Green dimming	0~255	Area2 Green dimming from dark to bright
CH16	Area 2 Blue dimming	0~255	Area 2 Blue dimming from dark to bright
CH17	Area2 white dimming	0~255	Area2 white dimming from dark to bright
CH18	Area3 Red dimming	0~255	Area3 Red dimming from dark to bright
CH19	Area3 green dimming	0~255	Area3 green dimming from dark to bright
CH20	Area3 Blue dimming	0~255	Area3 Blue dimming from dark to bright
CH21	Area3 white dimming	0~255	Area3 white dimming from dark to bright
CH22	Area4 Red dimming	0~255	Area4 Red dimming from dark to bright
CH23	Area4 green dimming	0~255	Area4 green dimming from dark to bright
CH24	Area4 Blue dimming	0~255	Area4 Blue dimming from dark to bright
CH25	Area4 white dimming	0~255	Area4 white dimming from dark to bright
CH26	Static gobo show	0~9	gobo1
		10~19	gobo2
		20~29	gobo3
		30~39	gobo4
		40~49	gobo5
		50~59	gobo6
		60~69	gobo7
		70~79	gobo8
		80~89	gobo9
		90~99	gobo10
		100~109	gobo11
		110~119	gobo12
		120~129	gobo13
		130~139	gobo14
		140~149	gobo15
		150~159	gobo16
		160~169	gobo17
		170~179	gobo18
		180~189	gobo19
		190~199	gobo20
		200~255	All images show by flow
CH27	Dynamic effect show	0~9	Effect1
		10~19	Effect2
		20~29	Effect3
		30~39	Effect4
		40~49	Effect5
		50~59	Effect6
		60~69	Effect7
		70~79	Effect8
		80~89	Effect9
		90~99	Effect10
		100~109	Effect11
		110~119	Effect12
		120~129	Effect13
		130~139	Effect14
		140~149	Effect15
		150~159	Effect16
		160~169	Effect17
		170~179	Effect18
		180~189	Effect19
		190~199	Effect20
		200~255	All images show by flow
CH28	The speed of effect	0~255	From fast to slow
CH29	Marco effect	0~49	No function
		50~99	Static gobo show(Built-in Effect)work together with the channel 18.8effect
		100~149	Dynamic effect show (Built-in Effect)work together with channel 19 . 8 .20
		150~199	Auto run
		200~255	Active mode
CH30	Reset	0~250	No function
CH30	Reset	251~255	Reset, it will be work after 3seconds

Red

Green

Blue

White
